BTA Deep Hole Drilling Machine
Zonap’s BTA Deep Hole Drilling Machine is engineered for industries where depth, diameter, and accuracy are non-negotiable. Built for large-diameter, long-depth drilling, this machine delivers exceptional straightness, superior surface finish, and rock-solid process stability—even in the toughest materials. From oil & gas to critical engineering, aerospace to heavy engineering, this machine is designed to dominate demanding drilling applications. With a high-power spindle, counter-rotation system, and high-pressure coolant technology, Zonap’s BTA machine transforms deep hole drilling into a fast, controlled, and reliable process. Multiple variants are available across different machine sizes and configurations to match varied drilling diameters, depths, and production requirements.
- Handles large diameters with high precision using BTA drilling system
- Delivers straight, smooth holes even at extreme depths
- High-power spindle for aggressive cutting in tough materials
- Counter-rotating workpiece for vibration-free drilling
- High-pressure coolant for clean chip evacuation
- Built for long, continuous production cycles
- Heavy cast‑iron structure for vibration‑free drilling
- FEM‑optimized rigid design
- High‑pressure coolant with automatic filtration
- Automatic chip conveyor
- Tool and process monitoring
- Oil & Gas: Drill collars, sleeves, tubular parts
- Aerospace: Structural and hydraulic components
- Automotive: Engine blocks, shafts, transmission parts
- Critical Engineering: Barrels, casings, critical long components
- Heavy Engineering: Large shafts and industrial tubes
- Replace cutting oil/coolant at regular intervals and clean the filtration system to prevent blockage and contamination.
- Check the clearance between guide bush and drill tool (recommended 0.01–0.03 mm). Replace the guide bush when wear is noticed.
- After every shift, clean drilling tools, apply anti-rust oil, and store in a dry, protected area.
- Inspect spindle, feed system, and counter-rotation system for smooth operation.
- Check belts, couplings, and bearings for abnormal noise or vibration.
- Verify coolant pressure and flow to ensure proper chip evacuation.
How to Maintain Deep Hole Drilling Equipment
- Replace cutting oil/coolant at regular intervals and clean the filtration system to prevent blockage and contamination.
- Check the clearance between guide bush and drill tool (recommended 0.01–0.03 mm). Replace the guide bush when wear is noticed.
- After every shift, clean drilling tools, apply anti-rust oil, and store in a dry, protected area.
- Inspect spindle, feed system, and counter-rotation system for smooth operation.
- Check belts, couplings, and bearings for abnormal noise or vibration.
- Verify coolant pressure and flow to ensure proper chip evacuation.
How to Clean CNC Deep Hole Drilling & Boring Machines
- Clean guideways, slides, and tailstock sleeve surfaces to remove chips, dust, and oil residue.
- Wipe ball screws, lead screws, smooth rods, and levers.
- Clean motor surfaces, electrical cabinets, belt covers, and panels from dust and oil stains.
- Clean coolant pump, filters, and chip conveyor.
- Check oil level in headstock/gearbox and refill up to the marked level.
- Lubricate guideways, slides, and moving parts using recommended oil.
- Apply grease to grease cups and lubrication points.
Regular maintenance and cleaning as per Zonap guidelines ensures longer machine life, higher accuracy, and trouble-free deep hole drilling performance.
Technical Specifications
| Category | Item | Specification |
|---|---|---|
| General | Machine Type | BTA Deep Hole Drilling Machine |
| Brand | Zonap | |
| Drilling | BTA Drilling Range | Ø30 – Ø200 mm (standard) |
| Max. Drilling Depth | 1000 mm, 2000 mm, up to 10000 mm (customizable) | |
| Spindle Quantity | 1 Set | |
| Workpiece Outer Diameter | Ø50 – Ø1000 mm | |
| Speed | Spindle Max. Speed | 1000 RPM |
| Feeding Speed | 0 – 3000 mm/min | |
| Workpiece Counter Rotation | 200 RPM | |
| Power | Spindle Motor | 30 kW (customizable) |
| Feeding Motor Torque | 27 N·m (customizable) | |
| High-Pressure Coolant Motor | 15 kW (customizable) | |
| Counter Rotation Motor | 0.75 kW (customizable) | |
| Chip Conveyor Motor | 0.2 kW (customizable) | |
| Total Machine Power | 45 kW (customizable) | |
| Coolant | Max. Pressure | 80 kg/cm² |
| Flow Rate | 200 L/min | |
| Chip Handling | System | Chain-type chip conveyor |
